The working principle of servo electric reducer

Low rpm planetary geared electric motor is the use of all levels of gear transmission to achieve the purpose of reducing speed. The servo reducer is composed of gear pairs at all levels. For example, using a small gear to drive a large gear can achieve a certain reduction in speed, and then using a multi-level structure, you can greatly reduce the speed.

Low RPM planetary geared electric motor. The power of the internal combustion engine or other high-speed operation through the input shaft of the reducer with a small number of teeth meshing the large gear on the output shaft to achieve the purpose of deceleration, the ordinary reducer will also have several pairs of the same principle of gear to achieve the ideal deceleration effect, the ratio of the number of teeth of the size of the gear is the transmission ratio.

Low rpm planetary geared electric motor

Low rpm planetary geared electric motor

1, reduce the speed while increasing the output torque, torque output ratio according to the motor output multiplier deceleration ratio, but be careful not to exceed the Low rpm planetary geared electric motor rated torque.

2, deceleration reduces the inertia of the load at the same time, and the reduction of inertia is the square of the deceleration ratio. You can look at the general motor has a value of inertia. The general reducer has helical gear reducer (including parallel shaft helical gear reducer, worm gear reducer, bevel gear reducer, etc.), planetary gear reducer, cycloidal pin gear reducer, worm gear reducer, planetary friction mechanical stepless transmission machine and so on.
